Finite
Element Analysis

Steel Stack Analysis

ANSYS Mechanical Enterprise + STAAD.Pro
  • Scope of Work :
    — Thermal Analysis of Stack for Skin Temperature
    — Wind Load Analysis
    — Seismic Load Analysis
    — Frequency Check
    — Deflection Check under Wind Load
    — Design of Base and Anchor Bolts
    — Girth Flange Strength Check
    — Stresses on Stack for Dynamic Loads

Nozzle Load Analysis

ANSYS Mechanical Enterprise (2019 R3)
  • Nozzle Type : Self-reinforced and Normal Pipe Type
  • Analysis Code : ASME Sec. VIII Div. 2 Part 5 (2017)
  • Design Pressure (Int. / Ext.) : 18.8 bar(g) / FV
  • Design Temperature (Int. / Ext.) : 115 / 93.3°C
  • MOC Shell : SA 516 70 N
  • MOC Nozzle : SA 106 GR. B / SA 105 N
  • Vessel Dimensions : ID 1600 X 3100 X 16 thk. mm
